Aluminum Alloy Exhibition Truss Wall System for Events
| 원래 장소 | 중국 장수 |
|---|---|
| 브랜드 이름 | Shizhan |
| 모델 번호 | 알루미늄 트러스 -RT |
| 최소 주문 수량 | 100 |
| 가격 | $30 |
무료샘플과 쿠폰을 위해 나와 연락하세요.
왓츠앱:0086 18588475571
위챗: 0086 18588475571
스카이프: sales10@aixton.com
만약 당신이 어떠한 관심도 가지면, 우리가 24 시간 온라인 도움말을 제공합니다.
x제품 상세 정보
| 재료 | 알루미늄 합금 | 유니트 길이 | 0.5m,1m,2m,3m,4m,5m 또는 주문 제작됩니다 |
|---|---|---|---|
| 트러스 섹션 모양 | 정사각형 또는 원형 | 모양 | 스퀘어, 트라이앵글이 만곡되거나, 특화했습니다 |
| 트러스 튜브 두께 | 1.5/2/3mm | 트러스 튜브 직경 | 20mm, 32mm, 50mm |
| 경도 | 16도 | 가벼운 의무 트러스 | 200*200mm; 250*250mm |
| 중간 근무 트러스 | 290*290mm, 300*300mm; 350*350mm, 300*400mm, 400*400mm, 450*450mm, 400*600mm | 트러스 | 520*760mm; 600*760mm; 600*1000mm |
| 메인 튜브 두께 | 30*2mm; 50*3mm; 50*4mm; 50*5mm | 바이스 튜브 두께 | 18*2mm; 20*2.5mm; 25*2.5mm |
| 브레이스 튜브 두께 | 20*2mm; 25*2mm; 30*2mm | 길이 | 0.5m/1m/1.5m/2m …… .4m 또는 사용자 정의 크기 |
| 트러스형 | 스피트 또는 볼트 | ||
| 강조하다 | aluminum alloy exhibition truss system,event truss wall system,aluminium lighting truss for events |
||
제품 설명
Standard Exhibition Aluminum Profile Wall System Booth Profile
Product Specifications
| Attribute | Value |
|---|---|
| Product Name | Standard Exhibition Aluminum Profile Wall System Booth Profile |
| Material | Aluminum alloy |
| Unit length | 0.5m, 1m, 2m, 3m, 4m, 5m or customized |
| Color | Silver, black or customized |
| Truss section shape | Square or round |
| Shape | Square, Triangle, round or customized |
| Truss tube thickness | 1.5/2/3MM |
| Truss tube diameter | 20mm, 32mm, 50mm |
| Hardness | 16 degree |
| Application | Concert, Music, Performance, DJ Band, Event, Exhibition |
Technical Details
| Truss Material | Aluminum alloy 6082-T6 |
| Light duty truss | 200*200mm; 250*250mm |
| Medium duty truss | 290*290mm, 300*300mm; 350*350mm; 300*400mm; 400*400mm; 450*450mm; 400*600mm |
| Heavy duty truss | 520*760mm; 600*760mm; 600*1000mm |
| Main tube thickness | 30*2mm; 50*3mm; 50*4mm; 50*5mm |
| Vice tube thickness | 18*2mm; 20*2.5mm; 25*2.5mm |
| Brace tube thickness | 20*2mm; 25*2mm; 30*2mm |
| Length | 0.5m/1m/1.5m/2m...4m or custom size |
| Truss type | Spigot or bolt |
| Truss Shape | Ladder truss, triangular truss, square truss, arch truss, circle truss |
| Color | Silver or black, blue, green... |
| Usage | Concert, new product release, fashion show, booth stand construction |
| Delivery Time | 10 working days |
Our aluminum alloy stage podium is a modular system made of lightweight aluminum alloy tubes that can be easily assembled and disassembled. It is widely used in various events including concerts, festivals, exhibitions, trade shows, and corporate events.
Common Applications
- Concerts and festivals: Used to build stages for outdoor events with configurable shapes and sizes, compatible with various accessories like guardrails and stairs.
- Theatrical productions: Ideal for constructing sets, backdrops, and other structures for plays, musicals, and operas with adjustable heights.
- Exhibitions and trade shows: Perfect for building booths and displays with customizable configurations to showcase products.
- Corporate events: Used for stages and backdrops at product launches, conferences, and award ceremonies with branding options.
- Sports events: Suitable for race start/finish lines, podiums, and scoreboards with sport-specific configurations.
This versatile and durable solution offers lightweight construction, easy assembly, and complete customization to meet specific event requirements. The modular design provides flexibility for event planners and organizers.
Frequently Asked Questions
Why should I choose your company instead of other suppliers?
- TUV, SGS, CE Certified products
- 15 years experience in truss, stage, barrier and scaffolding
- 35,000 m² workshop with excellent production capacity
- Professional engineering team for perfect project solutions
- Own aluminum profile production line for quality control
- Strict QC team ensuring product condition before delivery
- Process and final inspection with installation testing
How do I know your quality? Do you support sample orders?
Our products have TUV/SGS/CE/ISO9001 certifications. We offer samples for quality checking before batch orders.
Which payment methods do you accept?
T/T, Western Union, Trade Assurance, L/C.
What is your product warranty?
One year warranty covering non-artificial damage with free replacements.
Can you do customized designs?
Yes, our technical team provides perfect solutions for custom projects.
